| Standover Height |
65cm |
| Frame |
Butted Alloy Frame, 100/125mm Travel, Dropper Ready |
| Rear Shock |
DNM AO-38RC, 165x38mm Rebound Adjust, Pedal Platform |
| Fork |
RST FIRST AIR 15, 120mm Travel, 15mm Thru Axle, PM Disc Mount |
| Steerer |
Tube AL6061 |
| Cranks |
Samox 150mm Direct Mount |
| Axles |
Thru Axles AL7075, 15mm Front, 142 x 12mm Rear (1.0P) |
| Pedals |
SDG Slater 90 Pedals, Black |
| Bottom Bracket |
Samox 24mm External Cup, Sealed Cartridge Bearing |
| Rims |
24 X 28H, Double Walled AL6061, Tubeless Compatible |
| Rear Hubs |
CNC'D Straight Pull AL6061, 12x142 (1.0) Thru Axle |
| Front Hubs |
CNC’D Straight Pull AL6061, 15mm Thru Axle |
| Chain |
KMC X10 |
| Chainring |
Samox Direct Mount Steel 30T |
| Weight |
12.3kg W/O Pedals |
| Shifter |
Shimano SL-M5100-IR, DEORE, Right, 11-SP RAPIDFIRE |
| Rear Cassette |
Shimano CS-M5100-11, DEORE, 11-SP 11-51T |
| Brakes |
Shimano DEORE BL-MT6000, 160mm Rotors |
| Levers |
Shimano DEORE BL-M6000 |
| Front Tyre |
VEE Crown Gem Skinwall 24*2.25" 72 TPI, Folding |
| Rear Tyre |
VEE Crown Gem Skinwall 24*2.25" 72 TPI, Folding |
| Headset |
Semi Integrated, Tapered 1 1/8" - 1 1/5" Cartridge Bearing |
| Stem |
Ritchey OS Forged AL6061, 35mm Reach |
| Bars |
640mm Ritchey OS Double Butted AL6061, 18mm Rise |
| Grips |
Early Rider Lock On Kraton 120mm |
| Seat Post |
Ritchey, 30.9mm x 350mm, AL6061 |
| Saddle |
SDG Fly JR, Black |
| Seat Clamp |
Ritchey QR, 34.9mm |
| Derailleur |
Shimano RD-M5100, DEORE, SGS 11-SP |
